| Brand Name: | INYKO |
| Model Number: | Space Capsuse |
| MOQ: | 1 |
| Payment Terms: | T/T |
The Space Cabin is a high-end integrated space specially designed for high-end flexible office and long-term on-site scenarios. It integrates 35-42dB sound insulation and noise reduction technology, Grade 10-12 wind-resistant and anti-seismic steel structure, and comprehensive intelligent living and office configurations, aiming to solve problems such as insufficient privacy in high-end offices, inconvenience in long-term on-site living, and lack of business reception scenarios. With the integration of "high-end office + quality living" as its core, it offers two options: YS5 Standard Version and YS7 Deluxe Version, adapting to scenarios such as high-end open offices, long-term project sites, and business reception centers. Through configurations like panoramic balcony, electric skylight and intelligent equipment, it creates a quiet, safe and comfortable high-end comprehensive office and living environment for users, meeting both the needs of deep focused work and high-quality temporary living.
| Item | Specification |
|---|---|
| Sound Insulation Level | In an environment with noise of 80-90dB: Internal cabin sound insulation: 35±5dB; External cabin sound insulation: 15±5dB |
| Electrical Appliances | Inside the cabin: Ceiling ambient lights, Midea 2P inverter central air conditioner, Midea 80L electric water heater, Opple bathroom heater, Xiaomi high-end intelligent toilet Outside the cabin: LED ambient lights Optional: High-grade graphene electric floor heating, projector + projection screen, kitchen module |
| Dimensions | YS5 Standard Version: Length 8.5m * Width 3.3m * Height 3.2m (total area 28㎡) YS7 Deluxe Version: Length 11.5m * Width 3.3m * Height 3.2m (total area 38㎡) |
| Weight | YS5 Standard Version: 6.8 tons (including basic configurations) YS7 Deluxe Version: 8.6 tons (including basic configurations) |
| Color | Metal fluorocarbon baking paint (aluminum veneer shell); multiple custom colors available to match the style of high-end office scenarios |
| Material | Main frame: Hot-dip galvanized steel (main frame: 150*100*4.0mm, 100*100*3.0mm, etc.; auxiliary frame: 50*50*2.5mm, etc.) Shell: Custom 2.0mm aluminum veneer (metal fluorocarbon baking paint) Interior: 18mm cement fiberboard, SPC wood-plastic floor, high-grade custom carbon crystal board Glass: 6+12+6 double-layer insulated tempered Low-e glass (curtain wall); 6+1.52+6 laminated tempered glass (balcony/skylight) |
| Power Configuration | 10mm² whole-cabin cable access, 110V-250V power sockets, Cat6a network cables, card-swiping power-on + card-removal power-off system; optional additional power interfaces |
| Accessories | Foot cups/universal wheels (optional), custom electric blackout curtains, Cobbe bathroom accessories (shower heads, floor drains, etc.), German KINFUL washbasin; optional sofas/beds/projection screens/kitchen modules |
| Certifications | Anti-Seismic Rating Certification (Grade 10-12 wind resistance), Fire Resistance & Flame Retardancy Certification, Acoustic Performance Certification, Environmentally Friendly Material Certification (RoHS), Outdoor Waterproof Certification (door locks) |
This product is designed for high-end office and long-term temporary living scenarios; do not use it in scenarios with professional environmental requirements such as medical treatment and laboratories. The product quotation excludes taxes, transportation fees, hoisting fees, building foundation fees and optional configuration fees. The specific parameters, appearance and configuration brands are subject to the manual of the actually delivered model (the product is under continuous iteration, and configurations may be replaced with brands of equivalent quality). If product damage or safety accidents are caused by the user's non-compliant operations (e.g., overloading, unauthorized circuit modification, use of non-adaptable accessories), the warranty rights will be deemed waived, and the relevant losses shall be borne by the user.
